Product Introduction
Reuleaux RX GEN3 Dual, a new member of Reuleaux series, is more compact and portable than previous box mods. Powered by dual replaceable 18650 cells, the GEN3 Dual is able to output 230watts and has 2A quick charge capability. Featuring the unique crown molding shape and perfect color scheme, the gorgeous GNOME King atomizer that utilizes the updated WM01 coil for intense flavor can perfectly combine with RX GEN3 Dual in terms of appearance and performance.
Reuleaux RX GEN3 Dual
Parameter
Reuleaux RX GEN3 Dual

Size: 39.7*37.6*74.0mm Weight: 128.3g Max Output Wattage: 230W 1.3inch
  • Size: 39.7*37.6*74.0mm
  • Weight: 128.3g
  • Thread type: 510 spring loaded connector
  • Cell type: high-rate 18650 cell (discharging current should be above 25A)
  • Output mode: VW/TC-Ni/TC-Ti/TC-SS/TCR mode
  • Output wattage: 1-230W
  • Resistance range: 0.05-1.5ohm for TC modes
    Resistance range:0.1-3.5ohm for VW mode
  • Temperature Range: 100-315°C/200-600°F (TC modes)
  • Maximum Charging Current: 2A
  • Maximum Output Current: 50A
  • Output Voltage Range: 0.5-9V
GNOME King
  • Height: 57.0mm
  • Diameter: 26.0mm
  • Weight: 66.1g
  • E-liquid capacity: 5.8ml
GNOME King
  • Height: 57.0mm
  • Diameter: 22.0mm
  • E-liquid capacity: 2ml

Reuleaux RX GEN3 Dual
The GNOME King atomizer is shaped like a crown, offering you a high-end feeling. Moreover, the overall color scheme is perfect, providing you with great visual enjoyment and more options.

Reuleaux RX GEN3 Dual

Updated WM01 Coil for Large Vapor and Intense Flavor
The updated WM01 coil with brand-new shape is unique and powerful, offering more than you can imagine. The WM02 dual 0.15ohm head, WM03 triple 0.2ohm head and WM RBA are also compatible with the GNOME King atomizer.
Reuleaux RX GEN3 Dual

WM01 Single 0.4ohm Head
Rating: 40-70W
Best wattage: 50-60W
Reuleaux RX GEN3 Dual
WM02 Dual 0.15ohm Head
Rating: 30-70W
Best wattage: 45-60W
(optional accessory)
Reuleaux RX GEN3 Dual
WM03 Triple 0.2ohm Head
Rating: 40-130W
Best wattage: 70-90W
(optional accessory)
Reuleaux RX GEN3 Dual
WM RBA
(optional accessory)

Reuleaux RX GEN3 Dual

Smaller, lighter yet more Ergonomic
Comparing with other box mods, the GEN3 Dual is smaller, lighter and more ergonomic. The compact size and exquisite finish make it comfortable to hold and fashionable in appearance.

Dual 18650 Mod with 230W Max Output
Powered by dual replaceable 18650 cells, the GEN3 Dual is capable of outputting 230watts, providing you with large vapor clouds.

Reuleaux RX2 21700

Reuleaux RX2 21700

2A Max Charging Current for Quick Charge
With 2A maximum charging current, the batteries can be fully charged more quickly.

Reuleaux RX2 21700

Battery Balance Charge System
The balance charge technology brings the cells to an equal state of charge, making it much safer while charging.

Reuleaux RX2 21700

Dual Circuit Protection & Reverse Polarity Protection
Reverse polarity protection can be successfully achieved by the application of special anti reverse circuit in the board. And the dual circuit protection system make the GEN3 Dual much safe and reliable.
Reuleaux RX2 21700
Detachable Structure for Easy Cleaning
All parts of GNOME King atomizer can be detached and reassembled, bringing much convenience in cleaning it.

Reuleaux RX GEN3 Dual

Retractable Top Filling Solution & Convenient Bottom Airflow Control
Simply slide the top cap, you can finish the refilling fastly. By rotating the airflow control ring only, you can adjust the airflow to your preference.

Reuleaux RX GEN3 Dual
Reuleaux RX GEN3 Dual

Attractive colors, Rich Vaping Life
Available in charming looking and fashionable colors, GEN3 Dual can bring you unexpected visual enjoyment.

Upgradeable Firmware with Timeout Settings
Coming the upgradeable firmware, you can set the timeout duration as you like.
SINUOUS RAVAGE230
Charging
It is better to take out the cells and charge them through external charger
You can also charge the device by connecting it with a computer or a wall adapter via USB cable.
SINUOUS RAVAGE230
Standard Configuration
Reuleaux RX Machina
  • 1 * Reuleaux RX GEN3 Dual (no cells)
  • 1 * Glass Tube
  • 2 * Warning Card
  • 1 * GNOME King
  • 1 * QC USB Cable
  • 2 *WM01 Single 0.4ohm Head
  • 2 * User Manual
